Boeing 737 Main Landing Gear Design Prioritises Simplicity

Atypical Main Landing Gear Configuration

The Boeing 737 aircraft family, a staple in global aviation, employs a distinctive main landing gear design where the wheels do not retract fully behind protective doors. Unlike most other airliners, including the Airbus A320 and Boeing's own 757 model, the 737's main gear remains visible, flush with the fuselage underside, when stowed.

This configuration contrasts with the typical practice across the industry, where main landing gear bays are covered by doors to maintain aerodynamic efficiency during flight. Even widebody aircraft consistently feature fully enclosed main gear wells. Boeing addresses this by fitting the retracted wheels with hubcaps and rubber seals.

These elements work to preserve the aircraft's aerodynamic profile, a design feature present since the initial 737 variants were introduced.

Historical Rationale: Simplicity and Robustness

Boeing's decision to omit main landing gear doors on the 737 originated from its design brief in the 1960s. The aircraft was conceived for short routes, operating from smaller, less developed airfields where maintenance infrastructure was basic. For these conditions, Boeing prioritised simplicity and robustness.

A low-riding fuselage facilitated easier ground servicing for crews, while the absence of complex gear doors meant fewer components that could break. Repairing a damaged gear door in remote locations during the 1960s would have presented significant logistical challenges. While landing gear doors do improve fuel efficiency by reducing drag, they also add weight.

For the short-haul 737-100 and 737-200 models, the modest fuel burn reduction from doors was considered less beneficial than the weight savings achieved by omitting them. Boeing determined that the added weight would negate any aerodynamic gains over the typical short flight durations.

Legacy Design in Modern Aircraft

Although the 737 was initially a short-haul aircraft, its role has evolved significantly. Today, it operates as a major mainline aircraft, serving extensive routes between large cities, seating up to 200 passengers, and even undertaking transatlantic flights.

In contrast, Airbus's A320, designed more recently for cross-country capabilities, incorporates main landing gear doors as standard. The 737 programme, now almost 60 years old, has seen numerous refreshes, including the 737 Classic, Next Generation (NG), and MAX variants.

However, adapting the fundamental design to include main landing gear doors would necessitate extensive reengineering. Such a change would increase development costs, raise aircraft prices, and introduce risks of delays and certification challenges.

Regulators might even classify the modified aircraft as an entirely new type, rather than a variant, which would entail a more rigorous and costly certification process.

Boeing has consistently limited design changes to preserve the advantages of modifying an existing type, ensuring variants can be certified efficiently and cost-effectively, a strategy that has contributed to thousands of 737 Classic and 737NG sales.

Mitigating Aerodynamic Impact

Despite the exposed landing gear, Boeing has implemented engineering solutions to minimise the aerodynamic penalty. While retracted landing gear inherently generates significant drag, the manufacturer addresses this by installing rubber seals within the landing gear bays.

These seals close the gaps between the stowed gear and the fuselage walls, creating a smoother underbelly profile. Furthermore, the wheels themselves are fitted with large covers, which contribute to the overall aerodynamic streamlining of the aircraft's underside.

These simple, low-tech measures effectively reduce drag, helping to offset the fuel burn implications that might otherwise arise from the partially exposed main landing gear. The design demonstrates a pragmatic approach to balancing historical design constraints with modern operational requirements.

Implications for Aviation Operations and Design

The enduring design of the Boeing 737's main landing gear reveals a critical trade-off in aircraft manufacturing: balancing initial design simplicity and maintenance ease against long-term aerodynamic efficiency and the costs of extensive re-engineering.

For airlines operating 737s, the design means a slightly different operational cost profile compared to aircraft with fully enclosed gear, even with Boeing's drag mitigation efforts.

The continued reliance on a nearly 60-year-old airframe design for new variants, like the 737 MAX, demonstrates the significant financial and regulatory hurdles involved in developing entirely new aircraft types. This approach allows manufacturers to introduce updated models more quickly and affordably, but it also means carrying forward certain legacy design characteristics.

Future aircraft development will continue to weigh these factors, with efficiency gains often requiring fundamental design shifts, while market demands push for cost-effective updates to proven platforms.
